Product Details:
|
| Place Of Origin: | China | Brand Name: | Rainbow |
|---|---|---|---|
| Model Number: | ECG-8812 | Name: | ECG Device |
| Categories: | Medical Equipment | Power Source: | Electric |
| Warranty: | 1 Year | After-sale Service: | Online Technical Support |
| Display: | 7 Inch Touch Screen TFT LCD | Color: | White |
| High Light: | Touch Screen 12Lead ECG Machine,12 Channel ECG Machine,Software Storage 1000cases ECG Machine |
||
Features
1. 7 inch high resolution color touch screen..
2. Full alphanumeric keyboard with shortcut keys, efficient in operation.
3. Simultaneous 12 leads ECG acquisition and display.
4. Automatic ECG measurements and interpretation.
5. Internal storage up to 1000 cases, convenient for case review and statistic.
6. Built-in rechargeable lithium high capacity battery.
7. ECG data can be transmitted to PC via USB. ECG reports can be saved, opened, in PC via ECG playback software.
Specification
| Items | specification |
| Lead | Standard 12 leads |
| Sampling mode | Simultaneous 12 leads acquisition |
| Sampling rate | 1000Hz |
| A/D Converter | 24bits |
| Frequency response | 0.05~ 160Hz (-3db) |
| Operation mode | Manual, Auto, Rhythm, 1 channel 1 minute |
| Filter | AC Filter: 50 Hz / 60Hz EMG Filter: 25 Hz / 35 Hz / 45H2/75 Hz / 100 Hz / 150Hz DFT filter: 0.05H2/0.5H2 |
| CMRR | ≥100dB (addACfilter) |
| Input mode | Floating and defibrillation protection |
| Input Impedance | ≥50MΩ(10Hz) |
| Input circuit current | ≤0.05μA |
| Input dynamic range | ±10mVp-p |
| Patient leak current | ＜10μA |
| Calibration voltage | 1mV±2％ |
| Polarizing voltage | ≥±300mV |
| Time constant | ≥3.2s |
| Paper specification | 210mm (W)*30m(L) |
| Memory | 1000 cases |
| Recording mode | Thermal printing ystem |
| Noise level | ＜15μVp-p |
| Threshold | ≤20μV |
| Wave Gain/Sensitivity | 2.5mm/mV, 5mm/mV, 10mm/mV, 20mm/mV (standard sensitivity: 10mm/m V) |
| Wave/ Paper speed | 12.5mm/s. 25mm/s,50mm/s (±3% ) |
| Machine Dimension | 365.4*323*85 mm |
| Weight | 2600g (not including the paper) |
| AC | 100V~240V(50/60Hz) |
| DC | 14.4V, 2500mAh, 36.00Wh (Built-in rechargeable Li-ion battery) |
Packing List
Name: QTY
ECG machine: 1
ECG cable: 1
Limb electrodes: 4
Chest electrodes: 6
Grounding wire:1
Print paper: 1 roll
Power line: 1
Fuse: 2
Operation manual: 1
