Home ProductsMulti Parameter Patient Monitor

Ultra Thin 10.1'' Heart Rate Monitor Portable Multiparameter Monitor

Certification
China Hunan Province Rainbow Technology Co., Ltd. certification
China Hunan Province Rainbow Technology Co., Ltd. certification
I'm Online Chat Now

Ultra Thin 10.1'' Heart Rate Monitor Portable Multiparameter Monitor

Ultra Thin 10.1''  Heart Rate Monitor Portable Multiparameter Monitor
Ultra Thin 10.1''  Heart Rate Monitor Portable Multiparameter Monitor
Ultra Thin 10.1''  Heart Rate Monitor Portable Multiparameter Monitor Ultra Thin 10.1''  Heart Rate Monitor Portable Multiparameter Monitor Ultra Thin 10.1''  Heart Rate Monitor Portable Multiparameter Monitor Ultra Thin 10.1''  Heart Rate Monitor Portable Multiparameter Monitor Ultra Thin 10.1''  Heart Rate Monitor Portable Multiparameter Monitor Ultra Thin 10.1''  Heart Rate Monitor Portable Multiparameter Monitor

Large Image :  Ultra Thin 10.1'' Heart Rate Monitor Portable Multiparameter Monitor

Product Details:
Place of Origin: Hunan, China
Brand Name: RAINBOW
Certification: ISO13485, FSC
Model Number: PM-9000
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: US $285-398/unit
Packaging Details: Anti-Collision Film+ Carton Box
Delivery Time: 5-8 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 30000units/year

Ultra Thin 10.1'' Heart Rate Monitor Portable Multiparameter Monitor

Description
Product Name: Patient Monitor Size: 10 Inch
OEM: Available
High Light:

Ultra Thin 10.1'' Heart Rate Monitor

,

Multiparameter Heart Rate Monitor

,

10.1'' Portable Multiparameter Monitor





Basic parameters:



Brand Name: Rainbow
Size: 10.1 inch Ultra Thin
Model: PM-9000
Functions: ECG, Heart rate, oxygen saturation, NIBP,TEMP,RESP
Manufacturer: Hunan Rainbow Technology, Ltd.



Features:

1. Brand-new model design, combines Chinese classical elegance and European style.

2. Modularized and one-piece design,strong anti-interference capability, more stable functions,consumes less power.

3. High brightness and resolution 10.1-inch colorful TFT LCD display.

4. Built-in battery,standby time to 120 minus,AC/DC power conversion.

5. Unique Battery charge detection,displayable battery level.

6. Unique real person voice alarm,sound, light and word alarm,three-level intelligent alarm

7. Applying "15-350BP"wide-range heart rate measurement design according to features of newborns.

8. Applying"Double Overvoltage protection" to ensure the safety, consistency and accuracy under all conditions.

9. Blood pressure with new anti-movement,low perfusion measurement technology in order to guarantee the newborn  measurement accuracy.

10. Chinese, English, French, Russian, Portuguese, Turkish and other languages.

Ultra Thin 10.1''  Heart Rate Monitor Portable Multiparameter Monitor 0Ultra Thin 10.1''  Heart Rate Monitor Portable Multiparameter Monitor 1Ultra Thin 10.1''  Heart Rate Monitor Portable Multiparameter Monitor 2



Standard configuration:

PM-9000A multi parameter patient monitor×1 set, standard 5-leads ECG conductance joint connecting cables×1 set, standard adult blood pressure cuffs×1 set, adult SPO2 probe×1 set, TEMP probe×1 set, power plug line×1 set, grounding wire×1 set, English operation manual×1 set, three certificates×1 set.

Optional:

monitor cart / support bracket/wall hanger/mobile stand/oral stent

Children/newborn SPO2 probe,Children/newborn blood pressure cuffs



Technical parameters:

  • ECG

Lead mode;I,II,III,AVR,AVL,AVF,V1-6

Gain: ×0.25, × 0. 5, and × 1, × 2

Frequency: 0.5 Hz - 100 Hz

Common-mode signal inhibition: More than 70 dB

Scan rate: 12.5 mm / S, 25 mm / S, 50 mm / S standard three stalls.

HR: ± 5 BPM

Precision calibration signal: 1mv(peak, ± 3% accuracy)

ST Detection: measurement range (-2.0mV----+2.0mV)

Using Standard: meet the ANSI / AMI EC13 -2002 standard

Response time: 1s

Alarm: Sound and Light

Preset heart rate range: (Alarm over preset numerical)

Ceiling: 1-255 bpm adjustable

Threshold: 0-254 bpm adjustable



  • NIBP

Technology: Oscillography

Measurement method:more accurate with reverse measurement

Measurement units:mmHg/Kpa

Overvoltage protection:double safety protection

Measure time:less than 45S

Scope: Pressure Cuffs 0-250 mmHg

Measure accuracy:ANSI/AAMI SP10-2002 standard average accuracy and deviation

Inflatable cuffs: 180 mmHg (120mmHg for children

Inflatable cuffs follow: original SBP: + 30 mmHg

Measuring range:

SBP 60 mmHg~250 mmHg

Pmean 45 mmHg~235 mmHg

DBP 40 mmHg~220 mmHg

Measure accuracy:±1.1KPa(±8mmHg)±10%

Response time: 1s

Alarm: Sound and Light

Preset range: report (Numerical exceed preset alarm)

SBP maximum 1mmHg~255 mmHg

Threshold 0 mmHg~254 mmHg

DBP maximum 1mmHg~255 mmHg

Threshold 0 mmHg~254 mmHg

Alarm accuracy:±1 mmHg

Standard: ANSI/AAMI SP10-2002



  • SPO2

Range: 0-100%

Accuracy: 1%

Resolution: 1%

Pulse frequency: 20-250 times / min

Response time: 1s

Alarm: Sound and Light

Preset range: (report Alarm over preset numerical)

Ceiling: 1% - 100% adjustable

Threshold: 0% - 99% adjustable



  • TEMP

Technology: thermostat temperature probe

Measuring range: 20 ° C-45 ° C

Temperature resolution: 0.1%

Accuracy: ± 1 ° C

Response time: 1s

Alarm: Sound and Light

Preset range: report (numerical preset alarm over)

Maximum: 20.1 ° C-45.5 ° C adjustable

Threshold: 20 ° C-45.4 ° C Adjustable

Alarm accuracy:±1℃



  • RESP

Breathing frequency range: 0-60 bum

Accuracy: ± 1rpm

Response time: 1s

Gains options: × 1, × 2, × 0.5, and × 0.25 four trenches

Alarm: Sound and Light

Ceiling: 10-100 bpm adjustable

Threshold: 0 -99 bpm adjustable

Alarm accuracy:±1rpm



  • Printer(Optional)

Specification:three-channel thermal recorder



  • System

Screen:10.1 inches TFT screen of LCD

Battery: sealed maintenance-free lithium battery

Safety standard: lec601-1(GB9706.1)
