Product Details:
|
Product Name: | Electrocardiogram Machine | Built-in Battery: | Yes |
---|---|---|---|
After-sale Service: | Online Technical Support | Input Impedance: | > 50MΩ |
Time Constant: | > 3.2s | USB Flash Disk & SD Memory: | Support |
Highlight: | 240V Medical Ekg Ecg Machine,12 Leads Ekg Ecg Machine |
Features:
1. Latex free,easy to clean and repair
2. Automatic measurement,calculation,analysis,waveform freezing.
3. Support USB flash disk&SD memory
4. Data transmitting to PC via USB
5. Multi-langusge support
6. The machine can store over 400 ECG reports in its built-in flash.
7. Built-in rechargeable li-ion battery,AC/DC power conversion
8. Sensitive filters of ADS, HUM, and EMG.
9. Lead off& lack off paper detection function
10. Simultaneously acquisition of 12 lead, full screen display of 12 channel ECG waveforms.
11. Adapt to 110-240V,50/60HZ AC power supply
Packing list:
Name | QTY | Name | QTY |
ECG machine | 1 | Fuse | 2 |
ECG cable | 1 | Operation manual | 1 |
Limb electrodes | 4 | ||
Chest electrodes | 6 | ||
Grounding wire | 1 | ||
Print paper | 1 roll | ||
Power line | 1 |
Parameters of ECG Machine
CMRR | ≥ 100dB, with AC Filter | Calibrating voltage | 1mV± 3% |
Input circuit | Floating | Voltage tolerance | ± 500mV |
Input circuit current | ≤ 0.1µ A | Time constant | > 3.2s |
Resolution | 12bit/1000Hz | Frequent response | 0.05Hz~150Hz |
Operation mode | Manual/Auto | Noise level | ≤ 15µ Vp-p |
Filter | AC. EMG Filter | Threshold | ≤ 20µ V |
Drift filter | Anti-Drift System | Paper speed | 12.5, 25, 50mm/s (± 3%) |
Input Impedance | > 50MΩ | Sensitivity | 5,10,20mm/mV |
Patient current leakage | < 10µ A | Recorder | High resolution thermal printer |
Specification of fuse | T1.6A 250V Ø5×20 | Battery | Built-in rechargeable Li-ion battery 11.1V(2200mAh) |
Recording paper | Thermal recording paper | Package | 256mm*204mm*66mm |
