Product Details:
Place of Origin: Hunan, China
Brand Name: RAINBOW
Certification: ISO13485, FSC
Model Number: ECG-8812
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: US $550-630/unit
Packaging Details: Anti-collision film+ Carton box Carton box dimension: 45*21*39cm Gross weight: 5.6kg
Delivery Time: Within 3 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 30000units/year

14.8V Touch Screen Medical Ecg Machine Data Transfer By Software Pc

Description
Product Name: ECG/EKG Machine Resolution: 12bit/1000Hz
Voltage Tolerance: ± 500mV Battery: Built-in Rechargeable Li-ion Battery 14.8V(4000mAh)
Recording Paper: 216mm Wide Warranty: 1 Year
High Light:

touch screen medical ecg machine

,

14.8v medical ecg machine

,

touch screen portable ecg device

Medical Equipment 12 Channel ECG machine with Touch Screen ECG and data transfer by Software PC ECG



Parameters of ECG Machine



CMRR ≥ 100dB, with AC Filter Calibrating voltage 1mV± 3%
Input circuit Floating Voltage tolerance ± 500mV
Input circuit current ≤ 0.1µ A Time constant > 3.2s
Resolution 12bit/1000Hz Frequent response 0.05Hz~150Hz
Operation mode Manual/Auto Noise level ≤ 15µ Vp-p
Filter AC. EMG Filter Threshold ≤ 20µ V
Drift filter Anti-Drift System Paper speed 12.5, 25, 50mm/s (± 3%)
Input Impedance > 50MΩ Sensitivity 5,10,20mm/mV
Patient current leakage < 10µ A Recorder High resolution thermal printer
Specification of fuse T1.6A 250V Ø5×20 Battery Built-in rechargeable Li-ion battery 14.8V(4000mAh)
Recording paper Thermal recording paper Package 365mm×306mm×109mm


Function Features of ECG Machine

  • Adapt to 100-240V, 50/60Hz AC power supply
  • Historical data and patient’s information can be reviewed and printed.
  • Support USB flash disk & SD memory, stored reports can be saved, opened, analyzed in PC via ECG playback software.
  • The machine can store over 500 ECG reports in its built-in flash.
  • Standard RS232 and USB communication interfaces.
  • Connect with PC via ECG workstation software.
  • Sleep mode to save energy and extend LCD life
