Product Details:
|
Size: | 3.5 Inch | Weight: | 1.4 Kg |
---|---|---|---|
Brand Name: | RAINBOW | Product Name: | ECG Machine |
Highlight: | 12 Channel Portable ECG Machine,Portable Ecg Machine With Printer,3.5 Inch Patient ECG Machine |
Shape of ECG Machine:
Brand: | Rainbow |
Size: | 3.5 inch |
Model: | ECG-8803 |
manufacturer: | Hunan Rainbow Technology Co., Ltd |
Standard configuration: |
ECG8803 Electrocardiograph mainframe |
ECG suction bulb – one pair |
12-channel ECG lead |
AC adaptor |
Grounding wire |
Body/limb clamp – one set |
Power line |
Thermal print paper- two rolls |
Print paper scroll |
Operation manual |
Standard configuration:
ECG8803 Electrocardiograph mainframe
ECG suction bulb – one pair
12-channel ECG lead
AC adaptor
Grounding wire
Body/limb clamp – one set
Power line
Thermal print paper- two rolls
Print paper scroll
Operation manual
Parameters of ECG Machine |
Operation mode:Manual/Auto/storage |
Standard 12 leads:real-time ECG waveforms |
Measure mode:Simultaneously acquisition of 12 lead, |
Measure frequency:12Bit/1000Hz(1ms) |
AC filter:50Hz/60Hz |
EMG filter:25Hz/45Hz |
Drift filter:Auto adaption |
CMRR:≥95dB |
Input circuit:Floating with defibrillation protection |
Frequent response:0.05-160Hz(-3db) |
Sensitivity:Auto/2.5/5/10/20/40(mm/mv) |
Printing:High resolution thermal printer |
Communication interface:Standard USB/RS232 |
Safety standard:IEC I CF(GB9706.1-2007) |
Keypad panel:can input clinic information such as patient names |
Display:320*240 Graphical LCD |
