Internal power supply:built-in rechargeable li-ion battery for 8-hour battery life
Carefully inspect every cable, every item, for damage. If the package is damaged, please keep the package temporarily, check whether all the contents are in good condition against the packing list, and then dispose of after checking the mechanical and electrical functions. If the item is incomplete, damaged, or fails an electrical inspection, please feel free to contact us and we will fix it for you as soon as possible.
Functions & features
✔All-digital design, anti-baseline drift, anti-ac, anti-myoelectric interference;
✔Four operating modes: automatic, manual, rhythm and physical examination mode. The physical examination mode can record the lead freely, and the rhythm mode can record the 60-second waveform automatically.
✔Lead off display;
✔Built-in ECG simulator;
✔Both AC and DC, built-in large capacity rechargeable maintenance-free battery;
✔High resolution thermal matrix printout;
✔Baseline stability test to ensure a neat and beautiful ECG waveform every time;
✔Standard RS-232 communication interface, USB interface.
● 12-lead synchronous ECG acquisition；
● Equipped with high speed and high sensitivity hot spot recording system, with print trace depth adjustment function；
● 7-inch high-definition and wide-angle color LCD screen, capacitive touch control, 12-lead display;；
● Six ECG record combination modes；
● 3 channels/ (3+R) channels/dual-row 6-channels/single-row 6-channels/single/dual-row 12-channels six ECG display combination modes;
● Accurate ECG automatic diagnosis function, with heart rate exceeding alarm function, and freely set whether to print the measurement and analysis report；
● Full keyboard touch input to enter hospital and patient information；
● With real-time ECG waveform freezing function, it is easy to grasp the patient's important ECG waveform；
● Manual, automatic, rhythm, physical examination and other operating modes；
● With RS232 communication interface, USB interface and LAN network interface；
● External large capacity USB memory, can achieve the storage, playback and printing of historical data on the computer
Settings
✔Report style. Options: 3CH, 3CH + R, 3CH + 2, 6CH, 6CH + R, 12CH physical examination, rhythm.
✔Report waveform gain. Options: AUTO, 5mm / mV, 10mm / mV, 25mm / mV.
✔Report waveform speed. Options: 12.5mm / s, 25mm / s, 50mm / s.
✔Automatically record time. Options: 4 seconds, 8 seconds, 10 seconds, 12 seconds, 24 seconds, 36 seconds, 60 seconds
✔Average QRS. Options: 2 * 6, 2 * 6 + Mark, 3 * 4, 3 * 4 + Mark, 4 * 3, 4 * 3 + Mark, none.
✔Automatic analysis. Options: all, data, conclusion, none.
✔Lead mode. Options: Standard, Europe.
✔Recording mode. Options: automatic, manual.
✔Report specifications. Options: Standard, A4 paper.
✔Automatically adjust the baseline. Options: on, off.
✔Periodic record. Options: every 1 minute, every 1 minute, every 2 minutes, every 3 minutes, every 4 minutes, every 10 minutes, every 20 minutes, every 30 minutes, every 60 minutes, off.
✔Print depth. Options: Concentration 1, Concentration 2, Concentration 3, Concentration 4, Concentration 5, Concentration 6, Concentration 7.
✔Print width. Options: fine, standard, coarse.
✔Medical Examination Lead 1. Options: I, II, III, aVR, aVL, aVF, V1, V2, V3, V4, V5, V6.
✔Medical Examination Lead 2. Options: I, II, III, aVR, aVL, aVF, V1, V2, V3, V4, V5, V6.
✔Medical lead 3. Options: I, II, III, aVR, aVL, aVF, V1, V2, V3, V4, V5, V6.
Technical indicators
✔Common mode rejection ratio ≥100dB
✔The input circuit: Float, defibrillation
✔Input loop current ≤0.1чA
✔Sampling rate:12bit/1000HZ
✔Operating mod:Manual/automatic
✔The filter:Power frequency filter, EMG filter
✔Drift filtering: Anti-drift system
✔The input impedance＞50MΩ
✔Patient leakage current＜10чA
✔Fuse specification:T1.6A/ 250V Ø5×20
✔Recording paper specification: Scroll/folding thermal recording paper (110mm)
✔Calibration voltage:1mV±3%
✔Polarization resistance voltage:±500m V
✔Time constant≥3.2s
✔Frequency response: 0.05Hz ～ 165Hz
✔Noise level:≤15чVp-p
✔Minimum detection signal≤20чV
✔The feeding speed:12.5 mm/s,25mm/s, 50mm/s
✔The sensitivity:5,10,20 (mm/mV ±5 %)
✔Record:6 channel high-resolution thermal printing
✔The battery:10.8V/2.6Ah(28.08Wh)
✔Overall dimensions:320mm×230mm×78mm
✔Net weight:1.85KG
✔Size of packing box:390mm×300mm×215mm
✔Gross weight:4.5KG
