Product Details:
|
Instrument Classification: | Class II | Warranty: | 2 Years |
---|---|---|---|
Product Name: | Syringe Pumps | Application: | ICU,hospitals,pet Clinic |
Name: | Pump | Power Source: | Electricity |
Material: | Metal, Plastic | After-sale Service: | Online Technical Support |
Inventory: | Yes | MOQ: | 1 |
Highlight: | Volumetric Medical Syringe Pump,IPX4 Medical Syringe Pump,CF Type Syringe Infusion Pump |
Technical Parameters of Syringe Pump
Main features | Reliable and Safe: Advanced safety design able to stop infusion and alarm even if the CPU damage,the medical staff can ues it safely. |
Applicable syringe | 5ml,10ml,20ml,30ml,50/60ml |
The maximum flow rate range | 5ml syringe: 0.1ml/h~200ml/h |
10ml syringe: 1ml/h~300ml/h | |
20ml syringe: 1ml/h~400ml/h | |
30ml syringe: 1ml/h~600ml/h | |
50/60ml syringe: 1ml/h~1200ml/h | |
Precision | Better than ±2%; (but 5ml syringe and <1ml/h: Better than ±8%) |
Parameter range | 1, Flow-rate: 0.1~1200.0 ml/h, 0.1ml/h step; 2, Dose: 0.1~999.9 mg, 0.1mg step; 3, mg/kg/h: 0.001~999.999 mg/kg/h, 0.001 mg/kg/h step; 4, Body-weight: 1~300 kg, 1kg step; 5, KVO rate: 0.1~5.0 ml/h, 0.1 ml/h step; 6, Bolus rate: 0.1~1200.0 ml/h, 0.1 ml/h step; 7, Bolus volume: 0.1~99.9 ml/h, 0.1ml step |
Alarm | 1, Occlusion,0~175KPa, 8 grades of sensitivity; 2, Pressure sensor is abnormal; 3, Push rod fall off; 4, The drug running out; 5, The injection will finish; 6, The motor rotation fault; 7, Overtime pause; 8, Low battery; 9, Battery failure; 10, Battery temperature is too high; 11, Mains missing tips; 12, MCU fault, and stop injection. |
Data function | 1, Memory of parameter: Records the latest injection parameter for next operation; 2, Historical records: records latest 1000 injection events. (what/when/why,flow-rate, etc.) |
Safety classification | Class I; Internal power supply, CF type, IPX4 equipment |
Power supply | AC 100~240V, 50/60Hz, Built-in rechargeable Li-battery |
Power consumption:20VA | |
Working time of battery: 10h@5ml/h | |
Weight and size | 37cm(w)*24cm(h)*21cm(t); about 2.1kg |
Optional accessories | Wireless communicating module. |
Chinese Certificate | yes |
Packing
Product Size: 10.1*12.5*9CM
Package Size: 27*21*17CM
Net Weight: 1.2kg
Gross Weight: 1.7kg
Shipping:
Air shipping or Express courier is recommended if the order quantity was less than 20 units. It usually takes around 7 days to reach the destination. By ocean shipping, it normally takes 20-40 days depending on the destination port.
What is your MOQ?
1 unit
What is your lead time?
Within 3 days after receiving the payment
What is the payment terms?
TT(Bank Transfer), Paypal, Western Union, Moneygram, XTransfer.
What is the warranty period?
2 years warranty period
Lifetime online technical support
Do you offer OEM service?
Yes, we do
Contact Person: Lily
