Product Details:
Place of Origin: Hunan,China
Brand Name: RAINBOW
Certification: ISO13485,FSC
Model Number: PM-9000A
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD 280-580
Packaging Details: carton box
Delivery Time: Within 3 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 10000units/year

Safety Standard Multi Parameter Patient Monitor 12.1 Inch LCD TFT Display

Description
Weight: 2.45kg Product Name: Patient Monitor
Parameter: 6 Parameters
High Light:

GB9706.1 Multi Parameter Patient Monitor

,

12.1 Inch Multi Parameter Patient Monitor

,

TFT Screen Multiparameter Patient Monitoring System

Cheap Price High Quality 12 Inch Multi Parameter Patient Monitor

Basic parameters:

Brand Name:Rainbow
Size:12.1 inch
Model:PM-9000A
Functions:ECG, Heart rate, oxygen saturation, NIBP,TEMP,RESP
Manufacturer:Hunan Rainbow Technology, Ltd.


Standard configuration:PM-9000A multi parameter patient monitor×1 set, standard 5-leads ECG conductance joint connecting cables×1 set, standard adult blood pressure cuffs×1 set, adult SPO2 probe×1 set, TEMP probe×1 set, power plug line×1 set, grounding wire×1 set, English operation manual×1 set, three certificates×1 set.
Optional::three-channel thermal printer, monitor cart / support bracket/rack
Children/newborn SPO2 probe,Children/newborn blood pressure cuffs


Safety Standard Multi Parameter Patient Monitor 12.1 Inch LCD TFT Display 0

Safety Standard Multi Parameter Patient Monitor 12.1 Inch LCD TFT Display 1
Features:

1. Powerful analysis software function: pacemaker analysis,ST segment analysis, arrhythmia analysis, drug concentration level measurement, titrimeter to ensure quick access to all information for clinic decisions.
2. Suitable for emergency room, operating room, PACU, ICU and CCU
3. Used for adults, children, and newborns
4. Standard of the Ethernet protocols, supports for wired or wireless connection, central monitoring system can be composed of up to 64 monitors with online upgrading software.
5. Strong defibrillation protection, anti high frequency and muscle electricity for accurate measurement results.
6. Monitor software with more shortcuts and “one-step” menu management, more straightforward.
7. Strictly design and manufacture on the basis of CE standard for the basic safety, stability and durability.
8. New improvements in UI operation of the monitor software with larger and clearer icons
9. 2000-piece trend and data storage,200-set alarm events available for printing
10. Different interface can be set in different clinical departments
11. Personalized operation system,concise and straightforward
12. Various interfaces: A single guide, standard, large font, all leads to satisfy clinical needs
13. Operational parameter functions such as CO2 and IBP can be realized with plug and play.
14. More powerful anti-movement capability in blood pressure measurement, more precise measurement towards low perfusion and shaking fingers.
15. Anti-movement-interference to minimize failures and adjustable for low or high pulse measurement.
16. All leads, seven-channel synchronous ECG display
17. Modularized and one-piece design,strong anti-interference capability, more stable functions,consumes less power.
18. Brand-new model design, combines Chinese classical elegance and European style.
19. Built-in battery,standby time to 120 minus,AC/DC power conversion.
20. High brightness and resolution 12.1-inch colorful TFT LCD display.
21. Unique Battery charge detection,displayable battery level.
22. Applying “15-350BP”wide-range heart rate measurement design according to features of newborns.



Safety Standard Multi Parameter Patient Monitor 12.1 Inch LCD TFT Display 2

Technical parameters:

  • ECG

Lead mode;I,II,III,AVR,AVL,AVF,V1-6

Gain: ×0.25, × 0. 5, and × 1, × 2

Frequency: 0.5 Hz - 100 Hz

Common-mode signal inhibition: More than 70 dB

Scan rate: 12.5 mm / S, 25 mm / S, 50 mm / S standard three stalls.

HR: ± 5 BPM

Precision calibration signal: 1mv(peak, ± 3% accuracy)

ST Detection: measurement range (-2.0mV----+2.0mV)

Using Standard: meet the ANSI / AMI EC13 -2002 standard

Response time: 1s
Alarm: Sound and Light
Preset heart rate range: (Alarm over preset numerical)
Ceiling: 1-255 bpm adjustable
Threshold: 0-254 bpm adjustable


  • NIBP

Technology: Oscillography

Measurement method:more accurate with reverse measurement

Measurement units:mmHg/Kpa

Overvoltage protection:double safety protection

Measure time:less than 45S

Scope: Pressure Cuffs 0-250 mmHg

Measure accuracy:ANSI/AAMI SP10-2002 standard average accuracy and deviation

Inflatable cuffs: 180 mmHg (120mmHg for children

Inflatable cuffs follow: original SBP: + 30 mmHg

Measuring range:

SBP 60 mmHg~250 mmHg

Pmean 45 mmHg~235 mmHg

DBP 40 mmHg~220 mmHg

Measure accuracy:±1.1KPa(±8mmHg)±10%

Response time: 1s
Alarm: Sound and Light

Preset range: report (Numerical exceed preset alarm)

SBP maximum 1mmHg~255 mmHg

Threshold 0 mmHg~254 mmHg

DBP maximum 1mmHg~255 mmHg

Threshold 0 mmHg~254 mmHg

Alarm accuracy:±1 mmHg

Standard: ANSI/AAMI SP10-2002



  • SPO2

Range: 0-100%

Accuracy: 1%

Resolution: 1%

Pulse frequency: 20-250 times / min

Response time: 1s

Alarm: Sound and Light

Preset range: (report Alarm over preset numerical)

Ceiling: 1% - 100% adjustable

Threshold: 0% - 99% adjustable



  • TEMP

Technology: thermostat temperature probe

Measuring range: 20 ° C-45 ° C

Temperature resolution: 0.1%

Accuracy: ± 1 ° C

Response time: 1s
Alarm: Sound and Light
Preset range: report (numerical preset alarm over)
Maximum: 20.1 ° C-45.5 ° C adjustable
Threshold: 20 ° C-45.4 ° C Adjustable
Alarm accuracy:±1℃


  • RESP

Breathing frequency range: 0-60 bum
Accuracy: ± 1rpm
Response time: 1s
Gains options: × 1, × 2, × 0.5, and × 0.25 four trenches
Alarm: Sound and Light

Ceiling: 10-100 bpm adjustable

Threshold: 0 -99 bpm adjustable

Alarm accuracy:±1rpm


  • Printer(Optional)

Specification:three-channel thermal recorder


  • System

Screen:12.1 inches TFT screen of LCD
Battery: sealed maintenance-free lithium battery
Safety standard: lec601-1(GB9706.1)
