6 Parameter Portable Patient Monitor Color TFT LCD Display For Ambulance ICU

6 Parameter Portable Patient Monitor Color TFT LCD Display For Ambulance ICU
6 Parameter Portable Patient Monitor Color TFT LCD Display For Ambulance ICU 6 Parameter Portable Patient Monitor Color TFT LCD Display For Ambulance ICU 6 Parameter Portable Patient Monitor Color TFT LCD Display For Ambulance ICU

Large Image :  6 Parameter Portable Patient Monitor Color TFT LCD Display For Ambulance ICU

Product Details:
Place of Origin: Hunan, China
Brand Name: RAINBOW
Certification: ISO13485, FSC
Model Number: PM-9000 8 inch
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: carton box dimension: 35*22*29 cm
Delivery Time: Within 3 days
Payment Terms: L/C, Western Union, T/T, MoneyGram
Supply Ability: 30000units/year

6 Parameter Portable Patient Monitor Color TFT LCD Display For Ambulance ICU

Description
Stype: Portable Patient Monitor Size: 8 Inch
Weight: 3.0kg 6 Parameters: ECG,HR,NIBP ,SPO2, RESP, TEMP
High Light:

Color TFT Portable Patient Monitor

,

ICU Portable Patient Monitor

,

Ambulance 6 Parameter Patient Monitor

Light Weight 8 Inch 6 Parameters Portable Patient Monitor Color TFT LCD Display For Ambulance ICU



Product description

6 Parameters: ECG; HR/PR; NIBP; SPO2; TEMP; RESP





Features:
8 inches color TFT LCD display; compact; 1.3KG
new high-precision modules, new digital oxygen technology
Real time S-T segment analysis; arrhythmia analysis;
Up to 400 groups NIBP list, 60 alarm event records recall in storage.
Patient info input management function
Various interfaces: A single guide, standard, large font, all leads
Efficient resistance to interference of defibrillator and HF knife
1-7 level audio/visual alarming
Lasting working capacity with build-in rechargeable lithium battery
Applicable to bedside care ward, ICU/CCU/OR, emergency centers, family care and so on



6 Parameter Portable Patient Monitor Color TFT LCD Display For Ambulance ICU 0





Standard configuration (Packing include):

PM-9000 8 inch transport monitor ×1 set,

Built-in rechargeable lithium battery ×1 set,

Standard 5-leads ECG conductance joint connecting cables ×1 set,

Standard adult blood pressure cuffs ×1 set,

Adult SPO2 probe ×1 set,

TEMP probe ×1 set,

Power plug line ×1 set,

Grounding wire ×1 set,

English operation manual ×1 set.



6 Parameter Portable Patient Monitor Color TFT LCD Display For Ambulance ICU 1





Technical parameters

ECG

lead mode;I,II,III,AVR,AVL,AVF,V1-6

Gain: ×0.25, × 0. 5, and × 1, × 2

Frequency: 0.5 Hz - 100 Hz

Common-mode signal inhibition: More than 70 dB

Scan rate: 12.5 mm / S, 25 mm / S, 50 mm / S standard three stalls.

HR: ± 5 BPM

Precision calibration signal: 1mv(peak, ± 3% accuracy)

ST Detection: measurement range (-2.0mV----+2.0mV)

Using Standard: meet the ANSI / AMI EC13 -2002 standard

Response time: 1s

Alarm: Sound and Light

Preset heart rate range: (Alarm over preset numerical)

Ceiling: 1-255 bpm adjustable

Threshold: 0-254 bpm adjustable

NIBP

Technology: Oscillography

Mode: manual / automatic

Measurement units: mmHg / kPa

Scope: Pressure Cuffs 0-250 mmHg

Inflatable cuffs: 180 mmHg (120mmHg for children, 70mmHg for newborn)

Inflatable cuffs follow: original SBP: + 30 mmHg

Measuring range: SYS: 60-250 mmHg

DIA: 40-220 mmHg

MEAN: 45-235 mmHg

Response time: 1s

Alarm: Sound and Light

Preset range: report (Numerical exceed preset alarm)

SYS: maximum: 1-255 mmHg adjustable

Threshold: 0-254 mmHg adjustable

DIA: ceiling: 1 -255 mmHg adjustable

Minimum standards: 0-254mmHg adjustable

SPO2

Range: 0-100%

Accuracy: 1%

Resolution: 1%

Pulse frequency: 20-250 times / min

Response time: 1s

Alarm: Sound and Light

Preset range: (report Alarm over preset numerical)

Ceiling: 1% - 100% adjustable

Threshold: 0% - 99% adjustable

TEMP

Technology: thermostat temperature probe

Measuring range: 20 ° C-45 ° C

Temperature resolution: 0.1%

Accuracy: ± 0.1 ° C

Response Time: 1s

Alarm: Sound and Light

Preset range: report (numerical preset alarm over)

Maximum: 20.1 ° C-45.5 ° C adjustable

Threshold: 20 ° C-45.4 ° C Adjustable

RESP

Breathing frequency range: 0-60 bum

Accuracy: ± 1rpm

Response time: 1s

Gains options: × 1, × 2, × 0.5, and × 0.25 four trenches

Alarm: Sound and Light

Alarm range: (numerical preset alarm over)

Ceiling: 10-100 bpm adjustable

Threshold: 0 -99 bpm adjustable

Printer(Optional)



Specification: Dual channel thermal array data recorder

Print mode: Real time or event triggered record waveform and text

Accuracy: horizontal: 4oodpi vertical: 800dpi

Annotation: Date/ time(24 hours)

Optional wall bracket, mobile stand, visits backpack.

System

Screen:7/8 inches TFT screen of LCD

Battery: sealed maintenance-free lithium battery

Safety standard: lec601-1(GB9706.1)
