15 Inch Touch Screen Surgical Monitor For Operating Room

Certification
China Hunan Province Rainbow Technology Co., Ltd. certification
China Hunan Province Rainbow Technology Co., Ltd. certification
I'm Online Chat Now

15 Inch Touch Screen Surgical Monitor For Operating Room

15 Inch Touch Screen Surgical Monitor For Operating Room
15 Inch Touch Screen Surgical Monitor For Operating Room
15 Inch Touch Screen Surgical Monitor For Operating Room 15 Inch Touch Screen Surgical Monitor For Operating Room 15 Inch Touch Screen Surgical Monitor For Operating Room 15 Inch Touch Screen Surgical Monitor For Operating Room 15 Inch Touch Screen Surgical Monitor For Operating Room 15 Inch Touch Screen Surgical Monitor For Operating Room

Large Image :  15 Inch Touch Screen Surgical Monitor For Operating Room

Product Details:
Place of Origin: Hunan, China
Brand Name: RAINBOW
Certification: ISO13485, FSC
Model Number: PM-9000GTE
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: US $395-888/unit
Packaging Details: Anti-collision film+ Carton box Carton box dimension: 41*29.5*38cm Gross weight: 5.85kg
Delivery Time: Within 3 days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 30000units/year

15 Inch Touch Screen Surgical Monitor For Operating Room

Description
Product Name: Surgical Monitor Display Size: 15 Inch
Optional: Dual IBP、CO2、touch Screen、printer Properties: Diagnosis
Working Temperature Environment: 0 - 40 ℃ Parameter: Spo2,nibp,Resp,ECG,temp, PR
Shelf Life: 2 Years After-sale Service: Online Technical Support
High Light:

15 Inch Touch Screen Surgical Monitor

,

Operating Room Surgical Monitor

Medical Equipment Patient Monitoring Display 15 Inch Touch Screen Surgical Monitor for Operating Room



Specification

Warning

The patient monitor may not meet its performance specification if stored or used outside the manufacturer’s specified temperature and humidity range.

1.1 Classification

Anti-electroshock type Class I equipment

Anti-electroshock degree CF defibrillation

1.2 Accordant Standard

Medical Device Directive 93/42/EEC
EN60601-1:2005 or IEC60601-1:2005 Medical Electrical Equipment, Part 1: General Requirements for Safety
EN60601-1-1 or IEC60601-1-1 Medical Electrical Equipment, Part 1-1: General Requirements for Safety, Collateral Standard: Safety Requirements for Medical Electrical Systems
IEC60601-1-4 Medical Electrical Equipment, Part 1-4: General Requirements for Safety, Collateral Standard: Programmable Electrical Medical Systems
IEC60601-2-49 Medical Electrical Equipment, Part 2-49: Particular Requirements for the Safety of Multifunction Patient Monitoring Equipment
IEC 60601-1-2:2007 Electromagnetic Compatibility, Medical Electrical Equipment
ISO 21647:2009 Medical electrical equipment — Particular requirements for the basic safety and essential performance of respiratory gas monitors


1.3 Power Supply

100~240 VAC, 50/60 Hz, Pmax=60VA

1.4 Battery

2200 mAh 14.8V rechargeable Lithium battery

Operating time after full charge is more than 1.5 hours

Operating time after the first alarm of low battery will be about 5 minutes

Maximum charging time is less than 6 hours.

1.5 Environment

Temperature

Working 0 ~ 40 °C, 5 ~ 40 °C with CO₂

Storage -20 ~ 50°C

Humidity

Working 15% - 90 %

Storage 15% - 90 % (no coagulation)

1.6 Signal Interface

Network interface standard RJ45 Socket



1.1 ECG

1.1.1 Lead mode

5 Leads, I, II, III, AVR, AVL, AVF, V

1.1.2 Gain

´2.5mm/mV, 5.0mm/mV, 10mm/mV, 20mm/mV

1.1.3 Heart rate

Measure range:

Adult 15 ~ 300 bpm

Neonatal/Pediatric 15 ~ 350 bpm

accuracy ± 1%

resolution 1 bpm

1.1.4 Sensitivity

> 200 μV P-P

1.1.5 Differential Input Impedance

> 5 M ohm

1.1.6 CMRR

Diagnostic Mode >90 dB

Monitor Mode >110 dB

Surgery Mode >110 dB

1.1.7 Electrode offset potential

±300mV

1.1.8 Leakage Current

< 10 μA

1.1.9 PACE pulse detect

range ±2~±700mV

width 0.1~2ms

rise time 10~100µs

1.1.10 PACE pulse rejection

range ±2~±700mV

width 0.1~2ms

rise time 10~100µs

1.1.11 Baseline Recovery

< 3 s After defibrillation.

1.1.12 Signal Range

± 5 mV p-p

1.1.13 Bandwidth

Surgery 1 ~ 20 Hz

Monitor 0.5 ~ 40 Hz

Diagnostic 0.05 ~ 130 Hz







15 Inch Touch Screen Surgical Monitor For Operating Room 0

15 Inch Touch Screen Surgical Monitor For Operating Room 1

Packing

Packing terms: Anti-collision film+ Carton box

Carton box dimension: 41*29.5*38cm

Gross weight: 5.85kg

Shipping:

Air shipping or Express courier is recommended if the order quantity was less than 20 units. It usually takes around 7 days to reach the destination. By ocean shipping, it normally takes 20-40 days depending on the destination port.

15 Inch Touch Screen Surgical Monitor For Operating Room 2

FAQ

1.who are we?

     We are based in Hunan, China, start from 1997,sell to Domestic Market(50.00%),Southeast Asia(15.00%),Africa(10.00%),Central America(10.00%),Mid East(8.00%),South Asia(7.00%). There are total about 11-50 people in our office.



2.why should you buy from us not from other suppliers?

    Hunan Rainbow Technology Co,Ltd is a professional manufacturer and wholesaler in monitor with 19-year experience. In order to meets the marketing demand, our company cooperate with the America RMS Company to release a serials of PM-9000 parameters monitor.



3.what can you buy from us?

   Multi parameter Patient Monitor,ECG Machine,Infusion Pump,Syringe Pump,Nutritional Pump



4.what services can we provide?

  Accepted Delivery Terms: FOB,EXW,Express Delivery;
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T;
Language Spoken:English,Chinese

15 Inch Touch Screen Surgical Monitor For Operating Room 3
