ECG Veterinary Monitoring Machine vehicle Mounted Vet Specs Monitor

Certification
China Hunan Province Rainbow Technology Co., Ltd. certification
China Hunan Province Rainbow Technology Co., Ltd. certification
I'm Online Chat Now

ECG Veterinary Monitoring Machine vehicle Mounted Vet Specs Monitor

ECG Veterinary Monitoring Machine vehicle Mounted Vet Specs Monitor
ECG Veterinary Monitoring Machine vehicle Mounted Vet Specs Monitor ECG Veterinary Monitoring Machine vehicle Mounted Vet Specs Monitor ECG Veterinary Monitoring Machine vehicle Mounted Vet Specs Monitor ECG Veterinary Monitoring Machine vehicle Mounted Vet Specs Monitor ECG Veterinary Monitoring Machine vehicle Mounted Vet Specs Monitor ECG Veterinary Monitoring Machine vehicle Mounted Vet Specs Monitor

Large Image :  ECG Veterinary Monitoring Machine vehicle Mounted Vet Specs Monitor

Product Details:
Place of Origin: Hunan,China
Brand Name: RAINBOW
Certification: ISO13485,FSC
Model Number: PM-9000 8 inch
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD 230-330
Packaging Details: carton box
Delivery Time: Within 3 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 10000units/year

ECG Veterinary Monitoring Machine vehicle Mounted Vet Specs Monitor

Description
Size: 8 Inch MOQ: 1
OEM: YES
High Light:

ECG Veterinary Anesthesia Monitoring Machine

,

OEM Veterinary Anesthesia Monitoring Machine

,

Vehichicle Mounted Vet Specs Monitor

Asia Hot Sale Medical Better Price High Quality Vehichicle Mounted Veterinary Monitor Multi Parameter

6 Parameters: ECG; HR/PR; NIBP; SPO2; TEMP; RESP



Features:

new high-precision modules, new digital oxygen technology

8 inches color TFT LCD display; compact; 1.3KG

Real time S-T segment analysis; arrhythmia analysis;

1-7 level audio/visual alarming

Patient info input management function

Efficient resistance to interference of defibrillator and HF knife

Various interfaces: A single guide, standard, large font, all leads

Up to 400 groups NIBP list, 60 alarm event records recall in storage.

Lasting working capacity with build-in rechargeable lithium battery

Applicable to bedside care ward, ICU/CCU/OR, emergency centers, family care and so on

ECG Veterinary Monitoring Machine vehicle Mounted Vet Specs Monitor 0

Standard configuration (Packing include):

PM-9000 8 inch transport monitor ×1 set,

Built-in rechargeable lithium battery ×1 set,

Standard 5-leads ECG conductance joint connecting cables ×1 set,

Standard adult blood pressure cuffs ×1 set,

Adult SPO2 probe ×1 set,

TEMP probe ×1 set,

Power plug line ×1 set,

Grounding wire ×1 set,

English operation manual ×1 set.



Technical parameters

ECG

lead mode;I,II,III,AVR,AVL,AVF,V1-6

Gain: ×0.25, × 0. 5, and × 1, × 2

Frequency: 0.5 Hz - 100 Hz

Common-mode signal inhibition: More than 70 dB

Scan rate: 12.5 mm / S, 25 mm / S, 50 mm / S standard three stalls.

HR: ± 5 BPM

Precision calibration signal: 1mv(peak, ± 3% accuracy)

ST Detection: measurement range (-2.0mV----+2.0mV)

Using Standard: meet the ANSI / AMI EC13 -2002 standard

Response time: 1s

Alarm: Sound and Light

Preset heart rate range: (Alarm over preset numerical)

Ceiling: 1-255 bpm adjustable

Threshold: 0-254 bpm adjustable

NIBP

Technology: Oscillography

Mode: manual / automatic

Measurement units: mmHg / kPa

Scope: Pressure Cuffs 0-250 mmHg

Inflatable cuffs: 180 mmHg (120mmHg for children, 70mmHg for newborn)

Inflatable cuffs follow: original SBP: + 30 mmHg

Measuring range: SYS: 60-250 mmHg

DIA: 40-220 mmHg

MEAN: 45-235 mmHg

Response time: 1s

Alarm: Sound and Light

Preset range: report (Numerical exceed preset alarm)

SYS: maximum: 1-255 mmHg adjustable

Threshold: 0-254 mmHg adjustable

DIA: ceiling: 1 -255 mmHg adjustable

Minimum standards: 0-254mmHg adjustable

SPO2

Range: 0-100%

Accuracy: 1%

Resolution: 1%

Pulse frequency: 20-250 times / min

Response time: 1s

Alarm: Sound and Light

Preset range: (report Alarm over preset numerical)

Ceiling: 1% - 100% adjustable

Threshold: 0% - 99% adjustable

TEMP

Technology: thermostat temperature probe

Measuring range: 20 ° C-45 ° C

Temperature resolution: 0.1%

Accuracy: ± 0.1 ° C

Response Time: 1s

Alarm: Sound and Light

Preset range: report (numerical preset alarm over)

Maximum: 20.1 ° C-45.5 ° C adjustable

Threshold: 20 ° C-45.4 ° C Adjustable

RESP

Breathing frequency range: 0-60 bum

Accuracy: ± 1rpm

Response time: 1s

Gains options: × 1, × 2, × 0.5, and × 0.25 four trenches

Alarm: Sound and Light

Alarm range: (numerical preset alarm over)

Ceiling: 10-100 bpm adjustable

Threshold: 0 -99 bpm adjustable

Printer(Optional)



Specification: Dual channel thermal array data recorder

Print mode: Real time or event triggered record waveform and text

Accuracy: horizontal: 4oodpi vertical: 800dpi

Annotation: Date/ time(24 hours)

Optional wall bracket, mobile stand, visits backpack.

System

Screen:7/8 inches TFT screen of LCD

Battery: sealed maintenance-free lithium battery

Safety standard: lec601-1(GB9706.1)



ECG Veterinary Monitoring Machine vehicle Mounted Vet Specs Monitor 1
